TECHNICAL DATA
规格参数
General specifications
| Bulb | 0.5 W high performance LED |
|---|---|
| Luminous intensity | 1000 Lux (1 m distance) |
| Luminous flux | approx. 35 lumens |
| Battery type | 2x LR03 / AAA (type-tested) |
| Operating duration | approx. 3 h (continuous operation) |
| Ambient temperature | -20 ... 40 °C (-4 ... 104 °F) |
| Storage temperature | -40 ... 60 °C (-40 ... 140 °F) |
| Degree of protection | IP67 |
| Mass | approx. 102 g (with batteries) |
| Dimensions | Dimensions |
| W x H x Dapprox. 135 mm x 25 mm x 22 mm | W x H x Dapprox. 135 mm x 25 mm x 22 mm |
| W x H x D | approx. 135 mm x 25 mm x 22 mm |
| EU-type examination certificate | SEV 11 ATEX 0174 X |
| Marking II 2G Ex ib IIB T4 Gb [exsign] II 2D Ex ib IIIC T60°C Db | Marking II 2G Ex ib IIB T4 Gb [exsign] II 2D Ex ib IIIC T60°C Db |
| Marking | II 2G Ex ib IIB T4 Gb [exsign] II 2D Ex ib IIIC T60°C Db |
