TECHNICAL DATA
规格参数
General specifications
| Bulb | 2 W high performance LED |
|---|---|
| Luminous flux | 150 lumens (high power)22 lumens (low power) |
| Battery type | 3x LR06 / AA (type-tested) |
| Operating duration | 6-8 hrs (high power)6-30 hrs (low power) |
| Ambient temperature | -20 ... 40 °C (-4 ... 104 °F) |
| Storage temperature | -40 ... 50 °C (-40 ... 122 °F) |
| Degree of protection | IP67 |
| Mass | approx. 150 g (with batteries) |
| Dimensions | Dimensions |
| W x H x Dapprox. 134 mm x 41 mm x 35 mm | W x H x Dapprox. 134 mm x 41 mm x 35 mm |
| W x H x D | approx. 134 mm x 41 mm x 35 mm |
| ATEX approval | ATEX approval |
| ATEX certificateSEV 18 ATEX 0177 XATEX markingII 1G Ex ia IIC T4 Ga II 1D Ex ia IIIC T200 135°C Da | ATEX certificateSEV 18 ATEX 0177 XATEX markingII 1G Ex ia IIC T4 Ga II 1D Ex ia IIIC T200 135°C Da |
| ATEX certificate | SEV 18 ATEX 0177 X |
| ATEX marking | II 1G Ex ia IIC T4 Ga II 1D Ex ia IIIC T200 135°C Da |
