TECHNICAL DATA
规格参数
Supply
| Input voltage | 5 V DC |
|---|---|
| Power supply | 100 ... 240 V 50-60Hz, 12.5 W / 20 W max/operating |
| Interface type | Front side: 1 x DC, 1x Ethernet, Serial Admin, 1x USB-B to Server, HDMI to Server Back side: HDMI out, USB K/M, Terminal Block. Factory Reset Button |
| Operating temperature | 0 ... 55 °C (32 ... 131 °F) |
| Relative humidity | 20 % ... 80 % |
| Connection | Local connection: HDMI passthrough port, 2x USB-A port for keyboard and mouse control Remote connection: 1 Gigabit Ethernet (RJ-45) port IPv6/IPv4 dual stack, TCP/IP |
| Mass | 0.65 kg |
| Dimensions | 140 mm x 144 mm x 30 mm (l x w x h) |
| Mounting | Zero-U form factor; rack mountable vertically or horizontally (bracket kit included) |
| Scope of delivery | 1 locking power cord 1 HDMI cable 1 USB-B to USB-A cable 1 mounting bracket kit |
