TECHNICAL DATA
规格参数
General specifications
| Description | FDT frame application of PACTware Consortium e. V. for use of FDT 1.2 compatible system, device,-and communication manager of individual manufacturers. Presence of the Microsoft .NET Framework is a condition. |
|---|---|
| Connection | The HART multiplexer can be accessed by a RS-485 interface. For the connection to a PC the RS-485 to USB interface converter I-7561 is available. |
| Hardware requirements | see release notes |
| Software requirements | see release notes |
| Languages | English |
| Lincense agreement | The software is provided with a full license and includes the complete FDT DTM functionality. |
| Configuration | Configuration |
| Representation of the system configurationGraphic representation of all communication and device type managers in the tree structure. In case of online operation colour code for identification of defective units and simulation operation. Multiple windows can be opened simultaneously. It is therefore possible to view the set device parameters, to monitor the measurement value and to display the device diagnostic simultaneously.System planning, application processingGeneration of a configuration by means of a graphical application processing menu. Editing of available projects. Selection switch markings for each channel. Offline configuration, saving of project data to hard disk. Automatic comparison of the project plan to the actual available system when establishing connections on the device and parameter levels. | Representation of the system configurationGraphic representation of all communication and device type managers in the tree structure. In case of online operation colour code for identification of defective units and simulation operation. Multiple windows can be opened simultaneously. It is therefore possible to view the set device parameters, to monitor the measurement value and to display the device diagnostic simultaneously.System planning, application processingGeneration of a configuration by means of a graphical application processing menu. Editing of available projects. Selection switch markings for each channel. Offline configuration, saving of project data to hard disk. Automatic comparison of the project plan to the actual available system when establishing connections on the device and parameter levels. |
| Operating conditions | see release notes |
| Representation of the system configuration | Graphic representation of all communication and device type managers in the tree structure. In case of online operation colour code for identification of defective units and simulation operation. Multiple windows can be opened simultaneously. It is therefore possible to view the set device parameters, to monitor the measurement value and to display the device diagnostic simultaneously. |
| System planning, application processing | Generation of a configuration by means of a graphical application processing menu. Editing of available projects. Selection switch markings for each channel. Offline configuration, saving of project data to hard disk. Automatic comparison of the project plan to the actual available system when establishing connections on the device and parameter levels. |
