TECHNICAL DATA
规格参数
Electrical specifications
| Battery type | 1x LR14 according to IEC (type-tested) |
|---|---|
| Operating duration | 1 year |
| Accuracy | -5 / +15 seconds per month |
| Ambient temperature | 0 ... 50 °C (32 ... 122 °F) |
| Mass | approx. 2 kg |
| Dimensions | 400 mm x 60 mm |
| EU-type examination certificate | PTB 02 ATEX 2197 X |
| Marking II 2 G Ex ia IIC T4 Gb | Marking II 2 G Ex ia IIC T4 Gb |
| Marking | II 2 G Ex ia IIC T4 Gb |
| SGS approval | SGS approval |
| SGS certificateSGSNA/22/SUW/00077XSGS markingClass I, Division 1, Groups A, B, C, D, T4 | SGS certificateSGSNA/22/SUW/00077XSGS markingClass I, Division 1, Groups A, B, C, D, T4 |
| UKCA approval | UKCA approval |
| UKCA certificateCML 21UKEX 21404XUKCA marking II 2G Ex ia IIC T4 Gb | UKCA certificateCML 21UKEX 21404XUKCA marking II 2G Ex ia IIC T4 Gb |
| SGS certificate | SGSNA/22/SUW/00077X |
| SGS marking | Class I, Division 1, Groups A, B, C, D, T4 |
| UKCA certificate | CML 21UKEX 21404X |
| UKCA marking | II 2G Ex ia IIC T4 Gb |
| Scope of delivery | Ex-Time 40 Batteries Documentation |
