TECHNICAL DATA
规格参数
Electrical specifications
| Operating voltage | 1500 V DC / 1000 V AC max. for ATEX / IECEx |
|---|---|
| Operating current | 1000 A max. |
| Enclosure cover | threaded round cover |
| Cover fixing | flamepath thread |
| Degree of protection | IP66 (IP66/IP67 with O-ring) |
| Cable entry | see data table |
| Defined entry area | see data table |
| Material | Material |
| Enclosurealuminum alloyGlassthermo-resistant tempered glassFinishpainted grey | Enclosurealuminum alloyGlassthermo-resistant tempered glassFinishpainted grey |
| Mass | see data table |
| Grounding | M6 external/M5 internal grounding point |
| Enclosure | aluminum alloy |
| Glass | thermo-resistant tempered glass |
| Finish | painted grey |
| Ambient temperature | -50 ... 60 °C (-58 ... 140 °F) -20 °C ... 60 °C (-4 °F ... 140 °F) GUB*5* and GUBX*5* |
| EU-type examination certificate | INERIS 14 ATEX 0035X |
| Marking [Ex] II 2 GDEx d IIC GbEx tb IIIC Db | Marking [Ex] II 2 GDEx d IIC GbEx tb IIIC Db |
| Marking | [Ex] II 2 GDEx d IIC GbEx tb IIIC Db |
| IECEx approval | IECEx INE 14.0042X |
| Degree of protection | EN 60529 |
| Supplementary information | EC-Type Examination Certificate, Statement of Conformity, Declaration of Conformity, Attestation of Conformity and instructions have to be observed where applicable. For information see www.pepperl-fuchs.com. |
| Optional accessories | see data table |
