TECHNICAL DATA
规格参数
Electrical specifications
| Battery type | 3 x AAA-size batteries, 1.5 V DC, alkaline cells, type LR03 |
|---|---|
| Operating duration | approx. 80 h (continuous operation) |
| Physical | Bluetooth v2.1, Class 2, EDR |
| Transmitter frequency | 2402 ... 2480 MHz (Bluetooth) |
| Transmitter radiated power | max. 5.5 dBm |
| Detection range | 20 m in air |
| Antenna | integrated omnidirectional |
| Signal | HART-compliant trapezoidal wave at 1200/2200 Hz |
| Hardware requirements | any PC, PDA, laptop, or other computer with Bluetooth capability |
| Operating system | Windows® 7, 10 and 11 or any OS that supports Bluetooth COM port |
| FCC approval | FCC Part 15 B , FCC ID: 2A3WYID7 |
| IC approval | ICES-003 , IC: 30237-IDC747 |
| Operating temperature | -20 ... 50 °C (-4 ... 122 °F) |
| Storage temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Relative humidity | 0 ... 95 % non-condensing |
| Degree of protection | IP20 |
| Connection | HART I/O Interface cable , 0.5 mm² (20 AWG) fine-strand , termination test clips |
| Material | Polycarbonate |
| Dimensions | 88 mm x 42 mm x 19 mm |
| Height19 mmWidth42 mmLength88 mm | Height19 mmWidth42 mmLength88 mm |
| Cable length | 0.5 m |
| Height | 19 mm |
| Width | 42 mm |
| Length | 88 mm |
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. |
