TECHNICAL DATA
规格参数
Supply
| Input current | 4 mA |
|---|---|
| Power supply | 4 ... 12 V powered by DTR and RS-232 inputs No external power required |
| Interface type | RS-232 port |
| Signal | 0.5 ± 0.1 Vpp trapezoidal wave at 1200/2200 Hz |
| Output/interface | 1500 V DC |
| Electromagnetic compatibility | Electromagnetic compatibility |
| Directive 2014/30/EUEN 61326-1:2013 EN 62368-1:2014-08 | Directive 2014/30/EUEN 61326-1:2013 EN 62368-1:2014-08 |
| RoHS | RoHS |
| Directive 2011/65/EU (RoHS)EN IEC 63000:2018 | Directive 2011/65/EU (RoHS)EN IEC 63000:2018 |
| Directive 2014/30/EU | EN 61326-1:2013 EN 62368-1:2014-08 |
| Directive 2011/65/EU (RoHS) | EN IEC 63000:2018 |
| Operating system | Windows® 7, 10 and 11 or any operating system that supports serial COM ports |
| Operating temperature | -20 ... 50 °C (-4 ... 122 °F) |
| Storage temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Relative humidity | 0 ... 95 % non-condensing |
| Degree of protection | IP20 |
| Connection | DB-9 connector , 2-pin polarity-insensitive test clips |
| Material | Polycarbonate |
| Dimensions | 49 mm x 33 mm x 15 mm |
| Height15 mmWidth33 mmLength49 mm | Height15 mmWidth33 mmLength49 mm |
| Cable length | 1.8 m 2-strand wire terminating in 2 test clips |
| Height | 15 mm |
| Width | 33 mm |
| Length | 49 mm |
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. |
