TECHNICAL DATA
规格参数
Supply
| Input current | 11 mA at 5 V |
|---|---|
| Power supply | Powered by USB port No external power required |
| Interface type | USB port |
| Signal | 0.5 ± 0.1 Vpp trapezoidal wave at 1200/2200 Hz, 24 VDC at 40 mA to device |
| Output/interface | 1500 V DC |
| Operating system | Windows® 7, 10 and 11 |
| Operating temperature | -20 ... 50 °C (-4 ... 122 °F) |
| Storage temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Relative humidity | 0 ... 95 % non-condensing |
| Degree of protection | IP20 |
| Connection | USB (type A) Connector , test clips |
| Material | Polycarbonate |
| Dimensions | 75 mm x 33 mm x 15 mm |
| Height15 mmWidth33 mmLength75 mm | Height15 mmWidth33 mmLength75 mm |
| Cable length | 1.8 m 2-strand wire terminating in 2 test clips 15.2 cm cable terminating in 1 USB type A connector |
| Height | 15 mm |
| Width | 33 mm |
| Length | 75 mm |
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. |
