TECHNICAL DATA
规格参数
Supply
| Input current | 30 mA at 5 V for modem only , 255 mA at 5 V with device power and modem |
|---|---|
| Power supply | Powered by USB port , No external power required |
| Interface type | USB 2.0 port or higher |
| Signal | 0.5 ± 0.1 Vpp trapezoidal wave at 1200/2200 Hz, 24 VDC at 40 mA to device |
| Output/interface | 500 V DC |
| Electromagnetic compatibility | Electromagnetic compatibility |
| Directive 2014/30/EUEN 61326-1:2013 EN 62368-1:2014-08 | Directive 2014/30/EUEN 61326-1:2013 EN 62368-1:2014-08 |
| RoHS | RoHS |
| Directive 2011/65/EU (RoHS)EN IEC 63000:2018 | Directive 2011/65/EU (RoHS)EN IEC 63000:2018 |
| Directive 2014/30/EU | EN 61326-1:2013 EN 62368-1:2014-08 |
| Directive 2011/65/EU (RoHS) | EN IEC 63000:2018 |
| Operating system | Windows® 7, 10 and 11 |
| Operating temperature | -20 ... 50 °C (-4 ... 122 °F) |
| Storage temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Relative humidity | 0 ... 95 % non-condensing |
| Degree of protection | IP20 |
| Connection | USB (type A) Connector , red and black test clips |
| Material | Polycarbonate |
| Dimensions | 96 mm x 47 mm x 24 mm |
| Height24 mmWidth47 mmLength96 mm | Height24 mmWidth47 mmLength96 mm |
| Cable length | 1.8 m 2-strand wire terminating in 2 test clips , 15.2 cm cable terminating in 1 USB type A connector |
| Height | 24 mm |
| Width | 47 mm |
| Length | 96 mm |
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. |
