TECHNICAL DATA
规格参数
General specifications
| Radio distance (in open air) | max. 100 m |
|---|---|
| Operating voltage | 6.5 V DC |
| Current consumption | 1.1 A |
| Interface type | Bluetooth V4.0 EDR , Class 1 Electrical interfaces: RS-232 , USB |
| Transmitter frequency | 2.4 ... 2.4835 GHz (ISM band) |
| Electromagnetic compatibility | Electromagnetic compatibility |
| Directive 2014/30/EUEN 61000-6-2:2005 + AC:2005 , EN 61000-6-4:2007 + A1:2011 | Directive 2014/30/EUEN 61000-6-2:2005 + AC:2005 , EN 61000-6-4:2007 + A1:2011 |
| Explosion protection | Explosion protection |
| Directive 2014/34/EUEN 60079-0:2018 EN 60079-11:2012 | Directive 2014/34/EUEN 60079-0:2018 EN 60079-11:2012 |
| Radio and telecommunication terminal equipment | Radio and telecommunication terminal equipment |
| Directive 2014/53/EUEN 300328 V2.1.1:2016 , EN 301489-1 V2.2.0:2017 , EN 301489-17 V3.2.0:2017 | Directive 2014/53/EUEN 300328 V2.1.1:2016 , EN 301489-1 V2.2.0:2017 , EN 301489-17 V3.2.0:2017 |
| RoHS | RoHS |
| Directive 2011/65/EU (RoHS)EN 50581:2012 | Directive 2011/65/EU (RoHS)EN 50581:2012 |
| Directive 2014/30/EU | EN 61000-6-2:2005 + AC:2005 , EN 61000-6-4:2007 + A1:2011 |
| Directive 2014/34/EU | EN 60079-0:2018 EN 60079-11:2012 |
| Directive 2014/53/EU | EN 300328 V2.1.1:2016 , EN 301489-1 V2.2.0:2017 , EN 301489-17 V3.2.0:2017 |
| Directive 2011/65/EU (RoHS) | EN 50581:2012 |
| Supplementary standard conformity | EN 60950-1:2006+A1:2010+A2:2013+A11:2009+A12:2011 |
| Operating temperature | -20 ... 50 °C (-4 ... 122 °F) |
| Storage temperature | -40 ... 70 °C (-40 ... 158 °F) |
| Relative humidity | 95 % non-condensing |
| Degree of protection | IP40 |
| EU-type examination certificate | IBExU19ATEXB016XIECEx IBE 19.0026X |
| MarkingZone 2/22II 3G Ex ic IIC T4 GcII 3D Ex ic IIIC T135°C Dc | MarkingZone 2/22II 3G Ex ic IIC T4 GcII 3D Ex ic IIIC T135°C Dc |
| Marking | Zone 2/22II 3G Ex ic IIC T4 GcII 3D Ex ic IIIC T135°C Dc |
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. |
