TECHNICAL DATA
规格参数
Supply
| Power supply | 5 V DC (Power supply via USB) Crystal Oscillator: 20 MHz |
|---|---|
| Data rate | up to 3 MBit/s |
| Operation frequency | 2.4 GHz to 2.485 GHz |
| Bluetooth | Tx Output Power: 0 dBm (Bluetooth® v2.0, v2.1) and 4.7 dBm (Bluetooth® Smart)Rx Sensitivity: -82 dBm (Bluetooth® v2.0, v2.1) v4.0 low energy and v2.0, v2.1 wireless technologies |
| USB | USB 2.0 |
| Operating system | RM Shell 5 and newer Based on Microsoft® Windows 10 IoT Enterprise LTSC 2019 |
| Operating temperature | -30 ... 85 °C (-22 ... 185 °F) |
| Certificate | Certified for use in the VisuNet FLX System in ATEX and IECEx Zone 2/22 installations |
| Approved for | CE, FCC, RoHS, REACH and WEEE |
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. An additonal driver is required. Please refer to the software tool tab to install your specific driver. |
DOCUMENTS & DOWNLOADS
资料与附件
暂无 STP 图纸。
