产品数据表
Datasheet
已就绪 · 可下载下载文件
TECHNICAL DATA
规格参数
Ambient conditions
| Ambient temperature | -40 ... 80 °C (-40 ... 176 °F) |
|---|---|
| Storage temperature | -40 ... 80 °C (-40 ... 176 °F) |
| Relative humidity | max. 95 % , without condensation |
| Material | Material |
| HousingPolyamide PA 6.6 | HousingPolyamide PA 6.6 |
| Mass | approx. 28 g |
| Dimensions | 2.5 x 122 x 70 mm (0.1 x 4.8 x 2.8 inch) (W x H x D) |
| Height122 mmWidth2.5 mmDepth70 mm | Height122 mmWidth2.5 mmDepth70 mm |
| Mounting | on 35 mm DIN mounting rail acc. to EN 60715:2001 |
| Housing | Polyamide PA 6.6 |
| Height | 122 mm |
| Width | 2.5 mm |
| Depth | 70 mm |
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. |
DOCUMENTS & DOWNLOADS
资料与附件
STP 三维图纸
3-D
已就绪 · 可下载下载文件
点击“三维预览”后按需加载图纸。
图纸暂时无法预览时，可通过上方资料链接重试或下载。
