产品数据表
Datasheet
已就绪 · 可下载下载文件
TECHNICAL DATA
规格参数
General specifications
| Motion velocity | typical: 0.3 ... 1 m/s |
|---|---|
| Sensing range | Sensing range |
| Read distance1 ... 20 m distance to conveyor beltWidthConveyour belt: max. 20 m | Read distance1 ... 20 m distance to conveyor beltWidthConveyour belt: max. 20 m |
| Read distance | 1 ... 20 m distance to conveyor belt |
| Width | Conveyour belt: max. 20 m |
| Function | Output rate : max. 20 Hz (50 ms) Kommunikation : Ethernet (TCP/IP) |
| Operating system | Linux Debian 10 |
| Compatibility | compatible with LiDAR-scanner R2000 SD/HD/UHD , R2300 (single layer) |
| Volume detection | ± 3 % under reference conditions |
DOCUMENTS & DOWNLOADS
资料与附件
暂无 STP 图纸。
