TECHNICAL DATA
规格参数
General specifications
| Type | Power supply |
|---|---|
| Input voltage | 100 ... 240 V AC rated input voltage , 90 ... 264 V AC operating range |
| Input current | max. 0.4 A max. input power: 13.37 W |
| Input frequency | 50/60 Hz |
| Power consumption | (no-loading) max. 0.1 W |
| Output rated operating current | ≤ 2 A |
| Voltage | 5 V DC |
| Power | 10 W |
| Operating temperature | 0 ... 25 °C (32 ... 77 °F) |
| Storage temperature | -20 ... 80 °C (-4 ... 176 °F) |
| Relative humidity | 90 % non-condensing |
| Degree of protection | IP20 |
| Cable | international pin, DC plug type 4 x 1.7 x 12 mm (fork and groove), polarity: center "+" US plug, EU plug, UK plug |
| LengthL1.83 m | LengthL1.83 m |
| Mass | 100 g |
| Dimensions | 79 mm x 41 mm x 40 mm (W x H x D) |
| Length | 1.83 m |
| UL approval | UL 60950-1 (IT Equipment) |
| Supplementary information | Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com. |
