TECHNICAL DATA
规格参数
Indicators/operating means
| Key | Push-to-talk button operable with thick gloves Front-facing multi-function button Volume up / down Channel up / down On/Off switch Red Button |
|---|---|
| Sound level | up to 103 dB |
| Battery type | Li-Ion battery 3.7 V 2200 mAh |
| Operating duration | Stand-by time: approx. 74 h Actual use/operating time depending on use and set sound level (See table "Run times") |
| I/O ports | 3.5 mm jack connection |
| Bluetooth | yes |
| NFC | yes |
| Applications | ECOM Standard |
| Ambient temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Degree of protection | IP64 according to EN/IEC 60079-0 (ATEX/IECEx) IP 67 following EN/IEC 60529 (industrial standard) |
| Mass | 249 g |
| Dimensions | Dimensions |
| W x H x D8 cm x 12 cm x 2.5 cm Including mounting clip: 8 cm x 12 cm x 3.2 cmHeight12 cmWidth8 cmDepth2.5 cm | W x H x D8 cm x 12 cm x 2.5 cm Including mounting clip: 8 cm x 12 cm x 3.2 cmHeight12 cmWidth8 cmDepth2.5 cm |
| W x H x D | 8 cm x 12 cm x 2.5 cm Including mounting clip: 8 cm x 12 cm x 3.2 cm |
| Height | 12 cm |
| Width | 8 cm |
| Depth | 2.5 cm |
| ATEX approval | ATEX approval |
| ATEX certificateIBExU20ATEX1025 XATEX marking II 1G Ex ia IIC T4 Ga [exsign] II 2D Ex ia IIIC T135°C Db IP 64 [exsign] I M1 Ex ia I Ma | ATEX certificateIBExU20ATEX1025 XATEX marking II 1G Ex ia IIC T4 Ga [exsign] II 2D Ex ia IIIC T135°C Db IP 64 [exsign] I M1 Ex ia I Ma |
| ATEX certificate | IBExU20ATEX1025 X |
| ATEX marking | II 1G Ex ia IIC T4 Ga [exsign] II 2D Ex ia IIIC T135°C Db IP 64 [exsign] I M1 Ex ia I Ma |
| IECEx approval | IECEx approval |
| IECEx certificateIECEx IBE 20.0004XIECEx markingEx ia IIC T4 Ga Ex ia IIIC T135°C Db IP 64 Ex ia I Ma | IECEx certificateIECEx IBE 20.0004XIECEx markingEx ia IIC T4 Ga Ex ia IIIC T135°C Db IP 64 Ex ia I Ma |
| KCC approval | KCC approval |
| KCC certificate23-KA4BO-0356XKCC markingEx ia IIC T4 Ga | KCC certificate23-KA4BO-0356XKCC markingEx ia IIC T4 Ga |
| Approved for | South Korea |
| IECEx certificate | IECEx IBE 20.0004X |
| IECEx marking | Ex ia IIC T4 Ga Ex ia IIIC T135°C Db IP 64 Ex ia I Ma |
| KCC certificate | 23-KA4BO-0356X |
| KCC marking | Ex ia IIC T4 Ga |
| Scope of delivery | RSM-Ex Charging cable Charger Safety instructions Documentation |
