产品数据表
Datasheet
已就绪 · 可下载下载文件
TECHNICAL DATA
规格参数
Electrical specifications
| Current consumption | 50 mA (via USB) |
|---|---|
| Galvanic isolation | safe electrical isolation by reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff test voltage 3 kV, 50 Hz, 1 min |
| Electromagnetic compatibility | Electromagnetic compatibility |
| Directive 2014/30/EUEN 61326-1:2013 (industrial locations) | Directive 2014/30/EUEN 61326-1:2013 (industrial locations) |
| Directive 2014/30/EU | EN 61326-1:2013 (industrial locations) |
| Ambient temperature | -20 ... 60 °C (-4 ... 140 °F) |
| Connection | Connection |
| Device1 x µUSBComputer1 x Type A USB | Device1 x µUSBComputer1 x Type A USB |
| Mass | 50 g |
| Cable length | 1.5 m |
| Device | 1 x µUSB |
| Computer | 1 x Type A USB |
DOCUMENTS & DOWNLOADS
资料与附件
暂无 STP 图纸。
