TECHNICAL DATA
规格参数
Electrical specifications
| Rated surge voltage | 8 kV |
|---|---|
| Overvoltage category | III |
| Ambient temperature | -60 ... 105 °C (-76 ... 221 °F) |
| Storage temperature | -25 ... 60 °C (-13 ... 140 °F) |
| Pollution degree | 3 |
| Connection | screw terminals |
| Core cross section | 0.2 ... 6 mm2 rated core cross section 4 mm2 |
| Material | insulating material : Polyamide (PA) |
| Mass | 20 g |
| Dimensions | 6.2 x 42.5 x 45.8 mm (0.24 x 1.7 x 1.8 inch) (W x H x D) |
| Height42.5 mmWidth6.2 mmDepth45.8 mm | Height42.5 mmWidth6.2 mmDepth45.8 mm |
| Structure | single-row |
| Mounting | on 35 mm DIN mounting rail acc. to EN 60715:2001 |
| Height | 42.5 mm |
| Width | 6.2 mm |
| Depth | 45.8 mm |
